hg8145c huawei GPON onu1GE+3FE+1TEL+WIFI+USB ftth wifi modem hg8145c gpon onu

Minimum Order Quantity :	50pcs	Price :	Negociatable
Packaging Details :	Carton Box	Delivery Time :	7-15days
Payment Terms :	T/T,Western Union	Supply Ability :	10000pcs/Week

Place of Origin:	China	Brand Name:	OEM
Certification:	CE ROHS Anatel	Model Number:	hg8145c onu

Detail Information
Type:	FTTx Solutions	No. Of Fiber:	1.
Use:	FTTH	CPU:	Hg8145c
WLAN:	2.4GHz	Optical Interface:	SC/UPC Interface Class B+
WiFi Standard:	2 X 2 MIMO 802.11b/g/n	Maximum Number Of MAC Addresses Learned:	1024
Port:	Shenzhen/guangzhou/hongkong

Product Description

hg8145c huawei GPON onu1GE+3FE+1TEL+WIFI+USB ftth wifi modem hg8145c gpon onu 0

EchoLife HG series Optical Network Terminals (ONTs) are user-side devices in Huawei Fiber-To-The-House (FTTH) solutions and support ultra-bandwidth access for home or Small Office/Home Office (SOHO) users using GPON technologies.

EchoLife HG series ONTs provide POTS ports and FE/GE auto-negotiation Ethernet ports, enabling high-performance forwarding capabilities. Enhance future-proof services with Huawei EchoLife HG series ONTs, consisting of three main categories: bridging type, bridging + voice type, and gateway type.

Specification

NNI	GPON
Optical interface	SC/UPC interface Class B+
UNI	4FE+WiFi+USB
WiFi standard	2 x 2 MIMO 802.11b/g/n
Antenna gain	2dBi
Dimensions(W x D x H)	156mm×125mm×30mm (Without external antenna)
Power supply	Power supply: 11-14V DC, 1A; Input power: 150V~264V AC,50/60Hz
Operating temperature and operating humidity	0°C-+40°C; 5%-95%, non-condensing
Cooling	Passive cooling
Maximum number of MAC addresses learned	1024
L2 forwarding capability	2 Gbit/s downstream (with any length packets); 1 Gbit/s upstream (with any length packets)
IPv4 L3 forwarding capability	2 Gbit/s downstream (with any length packets); 1 Gbit/s upstream (with any length packets)
IPv6 L3 forwarding capability	500 Mbit/s (V300R013C00 to V300R015C00); 2 Gbit/s (V300R015C10 and later)
