Minimum Order Quantity :	50pcs	Price :	US $39.5-40.5
Packaging Details :	Carton Box	Delivery Time :	7-15days
Payment Terms :	T/T,Western Union	Supply Ability :	10000pcs/Week

Place of Origin:	China	Brand Name:	HUAWEI
Certification:	CE ROHS Anatel	Model Number:	wifi6 Eg8145X6

Detail Information
Power Adapter Input:	100-240 V AC, 50/60 Hz	System Power Supply:	11-14 V DC, 1.5 A
Installation Mode:	Desktop	Antenna:	External Antenna
Certification:	CE ROHS Anatel	Power Saving:	COC V7
High Light:	EG8145X6 GPON ONU ONT , WIFI6 GPON ONU ONT , Desktop Installation Huawei GPON ONU

Model Number: EG8145X6	Type: Gpon/ Epon, ONT ONU
Place of Origin: Guangdong, China	Brand Name: Huawei
Use: Terminal	Warranty Time: 1 year
Name: Huawei Onu EG8145X6	Condition: Original and Brand New
Antenna: External antenna	Ports: 4GE+1TEL+1USB+CATV+WIFI
Optical connecto: SC/UPC	Color: White
Gross Weight: About 500g	MOQ: 50 SET
Single-Mode Fiber: SMF	Application: Fiber Optical Onu

Parameters	Huawei OptiXstar EG8145X6
Dimensions (H x W x D)	35 x 195 x 125 mm (without external antenna and pads)
Weight (Without Power Adapter)	Approximately 372 g
Operating Temperature	0-40°C
Operating Humidity	5-95% RH (non-condensing)
Power Adapter Input	100-240 V AC, 50/60 Hz
System Power Supply	11-14 V DC, 1.5 A
UNI	4 x GE, 1 x POTS, 1 x USB 2.0, 2.4G/5G Wi-Fi 6
NNI	GPON
Maximum Power Consumption*	18 W
Antenna	External antenna
Installation Mode	Desktop
GPON Port	• Class B+ • Receiver sensitivity: -27 dBm to -29 dB • Overload optical power: -8 dBm • Wavelengths: US 1310 nm, DS 1490 nm • Wavelength Blocking Filter (WBF) of G.984.5 • Flexible mapping between the GEM port and TCONT • GPON: consistent with the SN or password authentication defined in G.984.3 • Bi-directional FEC • SR-DBA and NSR-DBA • Type B (single-homing and dual-homing)
Ethernet Electrical Port	• Ethernet port-based VLAN tags and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission • QinQ VLAN • Limit on the number of learned MAC addresses • MAC address learning • Auto port speeds (10/100/1000 Mbit/s)
POTS Port	• Maximum REN: 4 • G.711A/μ, G.729a/b, and G.722 encoding/decoding • T.30/T.38/G.711 fax mode • DTMF • Emergency calls (with the SIP protocol)
WLAN	• IEEE 802.11 b/g/n/ax (2.4G) • IEEE 802.11 a/n/ac/ax (5G) • 2 x 2 MIMO (2.4G) • 2 x 2 MIMO (5G) • Antenna gain: 5 dBi • WMM/Multiple SSIDs/WPS • 2.4G and 5G concurrency • Air interface rate: 574 Mbit/s (2.4G), 2.402 Gbit/s (5G) • Beamforming • Band steering • DL OFDMA • DL MU-MIMO • 1024 QAM • 160 MHz frequency bandwidth • WPA3
USB Port	• USB 2.0 • FTP-based network storage • File/Print sharing based on SAMBA • DLNA function
Power Saving	COC V7

EG8145X6 WIFI6 GPON ONU ONT External antenna Desktop Installation

EG8145X6 GPON ONU ONT

WIFI6 GPON ONU ONT

Desktop Installation Huawei GPON ONU

ApplicationTypical Solution:FTTH(Fiber To The Home) Typical Business:INTERNET,IPTV,WIFI ,VOIP etc
