8 Ports 1000m PoE Switch fanless cooling With 2 Reverse PoE Switch

Contact Now

8 Ports 1000m PoE Switch fanless cooling With 2 Reverse PoE Switch

Minimum Order Quantity :	100PCS	Price :	USD8-USD18
Packaging Details :	1189528mm	Delivery Time :	10-15WORKING DAYS
Payment Terms :	L/C, D/A, D/P, Western Union	Supply Ability :	5000000PCS/YEAR

Place of Origin:	SHENZHEN	Brand Name:	HK
Certification:	FCC, ce, RoHS, CE FCC RoHS ISO9001:2015	Model Number:	HK-F1R10

Detail Information
Communication Mode:	Full-Duplex & Half-Duplex	Transmission Rate:	10/100Mbps
Model Number:	HK-F1R10	Ports:	4+1ports
Operating Temperature::	-20~+55°C	Total PWR / Input Voltage::	65W (AC100-240V)
PoE Ports::	Port 1- 4	Switch Capacity::	1.6Gbps
Function::	POE
High Light:	8 Ports 1000m PoE switch , Fanless Cooling 1000m PoE switch , RoHS 8 ports PoE switch

Product Description

8 ports 1000m PoE switch with 2 reverse poe switch

Overview

HK-8EP+2E is a 100M POE Switch with 8 10/100Mbps POE ports, with VLAN DIP it can easily have access to VLAN function. There are 2 10/100Mbps uplink port. Longest POE distance can reach 250M.

It is designed for school, family, SEMs, small range surveillance and other network connections.

All ports support wire speed forwarding and the rate is up to 100Mbps.

Each port support 4KV port lightning protection to ensure stable operation.

8 Ports 1000m PoE Switch fanless cooling With 2 Reverse PoE Switch 0

8 Ports 1000m PoE Switch fanless cooling With 2 Reverse PoE Switch 1

8 Ports 1000m PoE Switch fanless cooling With 2 Reverse PoE Switch 2

Features

Ø 4*100Mbps POE ports, 2*100Mbps uplink ports

Ø Support 10/100M speed rate, MDI/MDIX and half/full-duplex and auto-negotiation

Ø Each port has complete LED indicator as power indicator, POE indicator, LINK/ACT

Ø VLAN DIP; and 250M long distance transmission

Ø Support IEEE802.d Spanning Tree to make network easier

Ø Support high performance QoS function on each port

Ø Support broadcast storm control

Ø Support 100-240V wide voltage input

Ø Support IEEE802.3x Flow control and Back pressure control

Ø Require no configuration and will instantly operate as soon as you power it up

Default with end-span (1/2+, 3/6-) power supply, Mid-span(4/5+, 7/8-) optional
All port support wire-speed forwarding, 64-1518 Frame can reach wire speed
Support wall mounted installation
Support 4K port lightning protection
Adopt low power consumption chips, stable and reliable
Adopt fanless cooling design, natural cooling
Support POE power supply, support IEEE802.3af and IEEE802.3at, each port can provide up to 30W power supply

Application

8 Ports 1000m PoE Switch fanless cooling With 2 Reverse PoE Switch 3

Specification

Standards	IEEE802.3 10Base-T IEEE802.3u 100Base-TX IEEE802.3af IEEE802.1q VLAN	IEEE802.3at IEEE802.3x Flow control IEEE802.3d Spanning Tree IEEE802.3p QoS
Certifications	CCC, CE, FCC, RoHS
Ethernet Port	Connector: RJ45 Data Rate: 10/100M adaptive Distance: 250m UTP Type: UTP-5E or higher level
POE Port	Power supply: end span Battery core: 1/2+, 3/6- POE port characteristics: 15.4/30W POE total power: 65W
Performance	Processing Type: Store and Forward Transmission mode: Full /Half duplex MAC Table Size: 1K Buffer Space: 448K bit Back bandwidth: 1.2G Time Delay: ＜150μs
Power	Power Type: built-in power supply Input Voltage: AC100V～240V 50/60Hz Connector: AC Socket Power Consumption: 1.4W～3W
Environment	Storage Temperature: -40～70℃ Operating Temperature: -10～55℃ Relative Humidity: 5-95% ( no condensation)
Warranty	1 year
Physical Characteristics	Dimension: 195×135×38mm Weight: 0.65kg Color: Metal, Blue

Order information

HK-4EP+2E	6*100M Ethernet port, 4 ports have POE function

Note: 1. Default with US standard; GB, EU standards as request.
