HUAWEI EG8145X6 WiFi Gpon ONU Router Optical Network Terminal
Contact Person : Anna
Phone Number : +852 68416561
WhatsApp : +85268416561
Minimum Order Quantity : | 50pcs | Price : | Negociatable |
---|---|---|---|
Packaging Details : | Carton Box | Delivery Time : | 7-15days |
Payment Terms : | T/T,Western Union | Supply Ability : | 10000pcs/Week |
Place of Origin: | China | Brand Name: | ZTE |
---|---|---|---|
Certification: | CE ROHS Anatel |
Detail Information |
|||
Product Name: | F668 | Type: | Optical Fiber Wifi Router |
---|---|---|---|
Fiber Interface: | SC/UPC OR SC/APC | Ports: | 4GE+2POTS+CATV |
Size:: | 370*175*115mm(length*width*height) | Power: | ≤12W |
High Light: | 12W Router ZTE ZXHN F688,IPTV router zte zxhn f688,4GE 2POST voip onu f688 |
Product Description
ZTE Optical Cat ZXHN F668 GPON ONT ONU 4GE + 2POST + CATV with WIFI
ZTE F668 (4GE+2POTS+CATV+2USB) GPON ONT Features:
ZXHN F668 is a GPON Optical Network Terminal designed for FTTH scenarios. It provides subscribers rich, colorful, individualized, convenient and comfortable triple-play services including voice, video (IPTC/CATV) and hgh speed internet access.
Main Function
• Supported service: VoIP, Internet, IPTV, CATV
• GPON: 8 T-CONTs, 32 GEM Ports
• VLAN: 802.1Q, 802.1P, 802.1ad
• MAC address table: 1k
• L3 function: DHCP server/client, DNS client, NAT
• IPv6: Dual Stack, DS-Lite
• VoIP: SIP/H.248, G.711/G.722/G.729, T.30/T.38
• Wi-Fi: 4 SSIDs, 2x2 MIMO, WPS
• Wi-Fi authentication: Shared key, 128-bit WEP, WPA-PSK, WPA2-PSK, WPA-PSK + WPA2-PSK
• Multicast: IGMP v1/v2 Snooping/Proxy, MLD v1 Snooping
• Multicast group per user port: 256
• QoS: service flow classification based on physical port, MAC address, VLAN ID, VLAN priority level, IP addressl SP/WRR/SP+WRR
• Management: local web management, OMCI, TR069
GPON Interface
• Optical port: 1 x GPON interface (SC/APC)
• Transmission distance: 0 - 20 km
• Transmit rate: 2.488 Gbps downstream ; 1.244 Gbps upstream
User Network Interface
• 4 x 10/100/1000Base-T: Half/full duplex ; Auto MDI/MDIX ; Auto negotiatioin
• 2 x POTS interfaces
• 1 x Wi-Fi interface: IEEE 802.11b/g/n @ 2.4 GHz
• 1 x RF coaxial connector for CATV
• 1 x USB 2.0 host interface
Optical Module
• Wavelength:
- Receiving: 1480 - 1500 nm
- Transmitting: 1290 - 1330 nm
- Third party wavelength: 1550 - 1560 nm
• Receiving Sensitivity: -28 dBm
• Transmitting Optical Power: 0.5 - 5 dBm
Specication
Q: Are you a manufacturer or trading company?
A: We are manufacturer of ONT and FTTH equipment in china,meanwhile we are primary wholesaler of brand new ONU OLT in china, that’s why We can offer good price and solution as well as technical support for our customer
